Mineral Monday: Close-Ups of Bullfrog Ore from the Original Bullfrog Mine, Nevada

I collected this hand sample from the Original Bullfrog mine, Nye County, Nevada, sometime back in the mid to late 1980s when doing recon in the area, then cut and polished it—probably with a company saw and grinding wheel. This specimen is no doubt the best one I still have (a few may have been lost during one or two house moves), although it's been a while since I looked through all my rock boxes. This one photo has already been featured in two earlier posts, here and here.

I've got a few more photos to show you. These zoom in so we can see the size of the shiny ore minerals contained within the rock: v.g. (visible gold) and a silvery-gray silver mineral.
Here's the other side of this same rock.

We'll be focusing in on the lower left.
I've zoomed in here. Can you see the shiny flecks?
Well, it's hard to see them without holding the rock up to the light and waving it back and forth to get the metallic glint, so I've circled the little bits in yellow and light blue (cyan). Yellow is for gold; cyan is for silver.
See them now?
Yes, these are very tiny flecks of native gold and a silver mineral. The silver mineral is probably either acanthite; Ag-bearing tetrahedrite, with Ag substituting for Cu in the solid-solution series with freibergite; or uytenbogaardtite.
Zooming in even farther, we can see the ore minerals without enlarging the photo.
A few of these show up really well.
Next time I get my hands on this sample—I think it's still up in Alaska—I'll see if I can get even better photos.
